Mobile crusher plant

Mobile crusher plant

Transportation: 11900-15400
Max Height(mm): 4060-5700
Delivery: 15-30 days

Introduction

Production Description:

Mobile crusher plant is mainly used in metallurgy, chemical industry, building materials, utilities and other materials processing operations often need to relocate, especially for highways, railways, hydropower projects and other operations stone mobility, users can process raw materials according to the type, size requirements of different materials and finished products using a variety of configurations.


Features:

1. Good movable:hort PP series plant is short in length,different crushing equipment were installed on a separate removable chassis, short wheelbase, small turning radius, can be flexible with operations in the region and on ordinary roads.
2.  reduce transportation costs of materials:  can be processed in the field of materials.
3. direct and effective operation: the integration of mobile plant, can be used independently, also can treach customers' targets based on the process of material type and product requirements.
4. more flexible and adaptable: PP Series tire mobile pant can be broken according to different process requirements form the "broken after the first screening," can also be composed of "broken after the first screening" process, according to the actual needs of crushing station.

Parameter

Item Unit MG938E69 MG1142E710 MG1349E912 MG1349SK87 MG1349SK110
Transportation Length mm 11900 13100 14600 14600 15400
Transportation Width mm 2550 2550 1950 1550 1950
Transportation Height mm 3650 4450 4500 4550 4500
Max Length mm 12100 13300 14600 14600 15400
Max Width mm 2900 2950 3300 3300 3300
Max Height mm 4060 4810 5300 5300 5700
Weight t 39 57 83 65 92
Tire configuration   Dual-axial Triaxial Triaxial Triaxial Tri-axial
Crusher   PE600x900 PE750X1060 PE900X1200 SKJ870X1100 SKJ1100X1300
Max feeding size mm 480 630 750 720 960
Adjusting range of discharge opening mm 65-160 80-140 100-200 85-150 125-260
Capacity t/h 90-180 110-320 220-450 125-350 350-720
Vibrating feeder   GZD960x3800 GZD1100X4200 GZD1300X4900 GZD1300X4900 GZD1300X4900
Main Belt conveyor   B800X8.5M B1000X9M B1200X9.5M B1200X9.5M B1200X9.5M
Side-opening
(Optional)
  B450X3M B500X3.5M B650X4M B650X4M B650X4M
Power of generator set
( Optional)
Kw 160 200 220 250 300
Iron-separator
(Optional)
  RCMD(C )-8 RCMD(C )-10 RCMD(C )-12 RCMD(C )-12 RCMD(C )-12
